Name: *MEI SWING CHECK CVS DN50 50BAR PN10/40 ANSI300RF
SKU: JSC11050
Availability: InStock

*MEI SWING CHECK CVS DN50 50BAR PN10/40 ANSI300RF

TITANIUM/TITANIUM/NBR

Beskrivelse

JSC11050 is 50mm – 2″ size and 50 bar pressure rated Swing Check Valve. Suitable for PN10, PN40 and ANSI300RF flanges with wafer style mounting. Body and disc material is Titanium, seat material is NBR.

Tilleggsinformasjon

Size	50mm – 2"
Valve Type	Swing
Pressure Rating	50 bar
Connection	Wafer
Flange Drilling	PN10/PN40/ANSI 300
Body Material	Titanium
Body Material Std.	Titanium Gr.2
Face To Face Distance (Mm)	14
Trim Material	Titanium
Trim Material Std.	Titanium Gr.2
Features	Without Spring
Max Temperature	80°C
Seat Ring Material Std.	NBR (Buna-N)
Sector	Industry
